מדריך BeSafe iZi Go Modular מושב לרכב

מדריך

8 9

! Vital information

• The child seat MUST NOT be installed in a front

passenger seat WITH AN ACTIVATED AIRBAG.

• iZi Go Modular can be installed rearfacing on iZi

Modular i-Size base or can be installed rearfacing with a 3-point

car belt, approved according to UN/ECE Regulation No.16 or other

equivalent standards.

• iZi Go modular is approved for children with a stature height from

40 to 75 cm, with a max. weight of 13 kg.

• The harness straps must always be locked when the child is in

the seat.

• The harness straps must be tightened without slack and not twisted.

• The shoulder pads contain magnets. Magnets can influence

electronic equipment such as pacemakers.

• Protect any part of the child’s body which is exposed to the sun.

• Remove the head space reducers on both sides from the headrest

when the child is older than 3 months or if the head is not fitting

anymore. These reducers can be removed by opening the velcro on

the back of the head rests.

• Remove the baby cushion (bottom part) when the child is taller

then 60 cm, or over 4 months.

• Remove the baby cushion (bottom part) and body hugger (upper

part) when the child is taller than 65 cm, or over 6 months.

• After an accident, the seat must be replaced. Although it may look

undamaged, if you were to have another accident, the seat may not

be able to protect your child to the level to which it was designed.

• Prevent the seat from becoming trapped or weighed down by

luggage, seats and/or slamming doors.

• Make sure you can fit no more than one finger between the harness

and your child (1 cm).

• DO NOT attempt to dismantle, modify or add any part to the seat.

Warranty will be void if non-original parts or accessories are used.

• Never leave your child unattended in the seat.

• Make sure all passengers are informed about how to release your

child in case of emergency.

• Make sure luggage or other objects are properly secured. Unsecured

luggage may cause severe injuries to children and adults in case

of accidents.

• Never use the seat without the cover. The cover is a safety feature

and may only be replaced by an original BeSafe cover.

• Do not use any aggressive cleaning products; these may harm the

construction material of the seat.

• BeSafe advises that child seats should not be bought or sold

second-hand.

• KEEP this user manual for later use with the seat.

• DO NOT use the seat for longer than 7 years. Due to ageing, the

quality of the material may change.

1 3

6

8

9

7 10

4

5

2

b

c

e

h

g

d

f

a

i

k

m

l

j

click!

11 16

19

20 21

17 18

12

14

15

13

click!

< 60 cm

0-4 months

60-65 cm

4-6 months

> 65 cm

> 6 months

> 25 cm

Thank you for choosing BeSafe iZi Go Modular

! It is important that you read this user manual BEFORE

installing your seat. Incorrect installation could endanger

your child.

! Warnings (EN 12790-2009) using the seat as a

reclined cradle

! IMPORTANT! KEEP FOR FUTURE REFERENCE.

• Never leave the child unattended.

• Do not use the seat as reclined cradle once your child can

sit unaided.

• This reclined cradle is not intended for prolonged periods of sleeping.

• It is dangerous to use this reclined cradle on an elevated surface, e.g.

a table.

• Always use the restraint system.

• This reclined cradle does not replace a cot or a bed. Should your

child need to sleep, then it should be placed in a suitable cot or bed.

• Do not use the reclined cradle if any components are broken

or missing.

• Do not use accessories or replacement parts other than those

approved by the manufacturer.

• If in doubt, consult either the car seat manufacturer or the retailer.

דירוג

למידע נוסף על המדריך זה

אנו מבינים שזה נחמד שיש מדריך נייר עבור הBeSafe iZi Go Modular מושב לרכב שלכם. אתם תמיד יכולים להוריד את המדריך מהאתר שלנו ולהדפיס אותו בעצמכם. אם אתם רוצים לקבל מדריך מקורי, אנו ממליצים ליצור קשר עם BeSafe. ייתכן שהם יוכלו לספק לכם מדריך מקורי. האם אתם מחפש את המדריך של הBeSafe iZi Go Modular מושב לרכב שלכם בשפה אחרת? בחרו את השפה המועדפת עליכם בדף הבית שלנו וחפשו את מספר הדגם כדי לראות אם הוא זמין אצלנו.
